Product Specification Details

Display System

• Projection System: DLP
• Resolution: 4K UHD (3840 × 2160)
• Brightness: 3200 ANSI Lumens
• Native Aspect Ratio: 16:9
• Supported Aspect Ratios: 4:3 / 16:9 / Auto / 2.4:1
• Contrast Ratio (Dynamic): 3,000,000:1
• Color Depth: 30-bit (1.07 Billion Colors)
• Light Source Life:
  • Normal Mode: 20,000 hours
  • ECO Mode: 30,000 hours

Optical

• Throw Ratio: 1.15 – 1.50
• Zoom Ratio: 1.3×
• Aperture (F/#): F/1.8 – 2.25
• Focal Length: 17.02 mm (Wide) – 22.21 mm (Tele)
• Lens Shift:
  • Vertical: ±30°
  • Horizontal: ±30°
• Vertical Keystone: 0% – 60%
• Horizontal Keystone: ±15%
• Projection Size: 60" – 300"

Video & HDR Support

• Wide Color Gamut: 100% DCI-P3
• HDR Support: HDR10 / HLG / HDR10+
• Dynamic Tone Mapping: Yes
• AI Cinema Mode: Yes
• 3D Support: Yes

Signal Compatibility

• Horizontal Scan Frequency: 15 – 135 kHz
• Vertical Refresh Rate: 23 – 120 Hz
• 3D Formats Supported:
  • Frame Sequential (PC)
  • Frame Packing (Blu-ray)
  • Side-by-Side (Streaming)
  • Top-Bottom (Streaming)

I/O Interfaces

• HDMI 3: HDMI 2.1 / HDCP 2.2 (4K 120Hz input, downscaled to 1080p 120Hz)
• HDMI 1: HDMI 2.0b / HDCP 2.2
• HDMI 2: HDMI 2.0b / HDCP 2.2
• HDMI (Internal): HDMI 2.0b / HDCP 2.2
• USB Type-A (2.0 / 2.5A Power Supply)
• USB Type-A (2.0 / 1.5A / Reader / Firmware Upgrade)

Audio

• Built-in Speaker: 5W
• Audio Output: Multi-Channel, RAW
• eARC Support: Yes
• Dolby Atmos Pass-Through: Yes

Environmental

• Operating Noise Level:
  • Normal Mode: 30 dB
  • ECO Mode: 29 dB

Physical Specifications

• Dimensions (W × H × D): 420.5 × 135.3 × 312.1 mm
• Weight: 6.1 kg
