Projection System

• Projection Type: Cinema
• Light Source: Blue Laser
• DLP Chip: 0.47" DMD
• Chipset: DDP7541 + MT9669
• Resolution: 4K UHD (3840 × 2160)
• Brightness: 2600 ANSI Lumens
• Native Aspect Ratio: 16:9
• Selectable Aspect Ratios:
  • 4:3
  • 16:9
  • Auto
  • Anamorphic 2.35:1
  • Anamorphic 16:9
  • 2.35:1
• Contrast Ratio: 2,000,000:1 (with Light Source Dimming)
• Color Depth: 30-bit (1.07 Billion Colors)

Color & HDR

• 100% DCI-P3
• HDR
• HDR10+
• HLG
• ISF Certified
• FILMMAKER MODE
• MEMC (Motion Enhancement)

3D Support

• Frame Sequential (PC)
• Frame Packing (Blu-ray)
• Side-by-Side (Streaming)
• Top/Bottom (Streaming)

Light Source Life

• Normal Mode: 20,000 hours
• ECO Mode: 25,000 hours

Lens System

• Throw Ratio: 1.52 – 2.45
• Zoom: 1.6× (Motorized)
• Lens Shift (Motorized):
  • Vertical: ±50%
  • Horizontal: ±21%
• Aperture (F/#): F/2.1 – 3.0
• Focal Length: 16.0 mm (Wide) – 25.7 mm (Tele)
• Projection Size: 60" – 300"

Keystone Correction

• 2D Keystone
  • Vertical: ±35°
  • Horizontal: ±35°

Scanning & Refresh

• Horizontal Frequency: 15K – 135KHz
• Vertical Frequency: 23 – 240Hz

Connectivity

HDMI

• HDMI-1 (2.0b / HDCP 2.2)
• HDMI-2 (2.0b / HDCP 2.2)

USB

• USB Type-A (2.0 / 2.0A Power / Media Reader)
• USB Type-A (2.0 / 1.5A Power / Media Reader)

Audio

• Built-in Speaker: None
• Audio Output:
  • 2-Channel PCM
  • Multi-Channel RAW
• eARC Support
• 7.1 Channel Audio Pass-Through

Noise Level

• 30 dBA (Normal)
• 27 dBA (Eco)

Physical Specifications

• Dimensions (W × H × D): 525.2 × 145.7 × 392.2 mm
• Weight: 10.5 kg
